Sync data from external sources

Open Register can keep a register in sync with an external system — another OR instance, a REST API, an FTP feed, or a database — through data sources. Each source has a connector, a target register / schema, a mapping, and a schedule. This tutorial walks through one source end-to-end.

Goal​

By the end you will have one configured data source, one successful sync run, and objects from the source visible in the target register.

Prerequisites​

  • Admin rights on Open Register (you need the register-admin role or Nextcloud admin).
  • A target register and at least one schema attached (see Create and attach a schema).
  • The external source's connection details — base URL, credentials, the endpoint or table that returns the rows you want.

Steps​

  1. Open Data sources in the navigation. The list shows existing sources with their status (active / disabled / error), last sync timestamp, and target register. Click Add Source.

    Data sources list with Add Source button

  2. Pick a connector type — REST API, OR instance, FTP / SFTP, Database, Excel file, Custom. Fill in the connection fields (URL, credentials, encoding). Open Register validates the connection straight away — Test connection in the toolbar reports OK or surfaces the protocol-level error.

    Connector type selected, connection tested

  3. Switch to the Mapping tab. The mapping picks the target register, the target schema, an optional filter (only sync rows that match), an optional key (which source field identifies a row — used for update vs create), and the field map between source columns and schema properties.

    Source-to-schema mapping

  4. Switch to the Schedule tab. Pick manual, every N minutes, hourly, daily, or a cron expression. For a first run leave it on manual — you trigger the first sync by hand so the failure modes are loud. Save the source.

    Schedule tab

  5. From the source detail page, click Run now. The toolbar reports Running…, then Done — N created, N updated, N errors. Open the target register's Objects tab — the synced rows are there, each one tagged with the source on its detail page.

    Sync run completed

Verification​

The source row in Data sources shows status active and a recent last sync timestamp; the target register has the expected number of new / updated objects; each synced object's Audit Trails tab lists the source as the trigger; re-running the sync produces 0 changes when nothing on the source side has moved.

Common issues​

SymptomFix
Connection test fails with TLS / cert errorThe connector verifies certificates by default — install the CA chain on the Nextcloud server, or set the source to Skip TLS verification (only on trusted networks).
Sync reports "0 errors" but no objects appearThe mapping's target schema doesn't match the source rows — re-check the Mapping tab and add at least one required property.
Every run creates duplicatesThe mapping has no key field set — Open Register can't tell update from create. Set the key to whichever source field is unique.
Scheduled sync stops runningThe Nextcloud cron is not active — php occ background:cron or systemd timer needs to be running every 5 min.
